Süha Bey Özel

Name: Süha Bey Özel
Brand: Evcik
SKU: EVCIK-DSGN-117
Price: 9083.69 TRY
Availability: InStock

€163.93

OkiFix sistemli hazır evcik — 240×360 cm, 35 parça. 3D önizlemeyi döndürerek inceleyin; “Bu Evciği Düzenle” ile ölçüleri kendinize göre uyarlayın.

This product is added to the cart as 23 line items (119 parts in total) (profiles, OkiFix connectors and bolt sets) — see the full breakdown in the "Parts List" tab.

Edit This Evcik Assemble This Evcik

SKU: EVCIK-DSGN-117 Category: Custom Projects

Description

Bu ürün, evcik tasarım uygulamasıyla hazırlanmış 240×360 cm ölçülerinde bir OkiFix konstrüksiyondur. Vidasız-kaynaksız OkiFix bağlantı sistemi sayesinde parçalar sökülüp yeniden kurulabilir.

Sepete eklediğinizde ürünü oluşturan tüm parçalar (profiller, OkiFix bağlantılar ve cıvata setleri) tek tek sepetinize eklenir — “Parça Listesi” sekmesinden tam dökümü ve paket bilgilerini görebilirsiniz.

Ölçüleri veya yerleşimi değiştirmek isterseniz “Bu Evciği Düzenle” butonuyla tasarımı kendi hesabınızda açıp düzenleyebilir, kendi sürümünüzü sipariş edebilirsiniz.

Parts List

All the parts that make up this Evcik are listed below; when you add it to the cart, this list is transferred to your cart exactly as shown. Prices include VAT.

Part	Length	Qty	Unit Price	Amount
Three-Way Corner Connector for 40×40 mm 2 mm Wall Thickness Box Profiles 4040CR03-1	—	3	€4.56	€13.68
11.25° Narrow Angle Left-Facing Three-Way Corner Connector for 40×40 mm Box Profiles 4040LA03-3	—	1	€4.80	€4.80
11.25° Narrow-Angle Right-Facing Three-Way Corner Connector for 40×40 mm Box Profiles 4040LA03-2	—	1	€4.80	€4.80
11.25° Wide Angle Left-Facing Three-Way Corner Connector Compatible with 40×40 mm Box Profiles 4040LA03-5	—	1	€4.80	€4.80
11.25° Wide-Angle Right-Facing Three-Way Corner Connector Compatible with 40×40 mm Box Profiles 4040LA03-4	—	1	€4.80	€4.80
Two-Way L Connector for 40×40 mm 2 mm Wall Thickness Box Profiles 4040CR02-1	—	1	€3.24	€3.24
Three-Way T Connector for 40×40 mm Box Profiles with 2 mm Wall Thickness 4040ED03-1	—	3	€4.32	€12.96
11.25° Angle Three-Way T Connector for 40×40 mm Box Profiles 4040LA03-1	—	1	€4.56	€4.56
11.25° Sloped-Top Three-Way T Connector for 40×40 mm Box Profiles 4040LA03-6	—	2	€4.56	€9.12
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	2720 mm	1	€6.47	€6.47
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	2270 mm	2	€5.51	€11.02
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	2420 mm	2	€5.83	€11.66
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	1721 mm	3	€4.33	€13.00
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	2775 mm	1	€6.59	€6.59
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	1890 mm	4	€4.70	€18.78
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	980 mm	1	€2.75	€2.75
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	360 mm	1	€1.42	€1.42
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	960 mm	1	€2.70	€2.70
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	2072 mm	1	€5.08	€5.08
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	1755 mm	1	€4.41	€4.41
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	1360 mm	2	€3.56	€7.12
40×40 mm Ready-to-Assemble Cut and Drilled Steel Profile (2 mm)	1720 mm	1	€4.33	€4.33
M6x45 Bolt and Nut	—	84	€0.07	€5.84
Total				€163.93
